Description
Price displayed is for ONE (1) wheel.
The Monoforged Series symbolizes a new generation of off-road wheels, where new streamlined wheel designs are precision machined out of structural 6061-T6 aluminum alloy (commonly used in aerospace), then finished in the latest and greatest painting line technology. This is the Monoforged Series by RRW. (Manufacturing process video coming soon.)
Optimization & construction:
-
Each design is streamlined for maximum weight savings, such as large chamfers, milled-out pockets, anywhere possible without compromising structural integrity.
- CNC machined from 6061-T6 billet forging, these wheels are lighter and stronger than ever compared to any cast counterpart. Period.
Premium paint:
-
Guaranteed - better than ever paint quality. These are the best wheels we’ve made to date.
- Flawless precision machining. With our Monoforged series, it’s all about the fine details.
Lighter than ever:
-
About 15-20% lighter than their cast counterparts in the same model & size.
-
The -S in a 17x8.5 +0 offset is just right under 20 lbs (that’s designed to a 2500 load rating standard) - This could be the lightest off-road wheel currently on the market.
- Engineered to a load rating of 2500 lbs per wheel. Enough to support any loaded ½ truck in the roughest conditions.
-
Now with deeper holes with more (50%) more thread engagement on the -H hybrid series. 25 tapped holes with a M8x1.25 thread pitch
- Billet CNC Aluminum center caps are included as standard option.
- Compatible with our ET lug nuts for maximum thread engagement to wheel studs. Great especially since Toyotas are notorious for having short wheel studs.
Lead times & shipping: We currently have limited inventory in stock. Orders will be shipped via Fedex Ground and will require signature.
Specifications:
- Size: 17x8.5
- Bolt pattern: 5x150, 6x135, 6x5.5/6x139.7
- Center bore for 5x150 : 110.1 mm (hub-centric for Tundra).
- Center bore for 6x135 : 87.1 mm (hub-centric for F150).
-
Center bore for 6x5.5 : 106.1 mm (hub-centric for Toyota trucks and GX).
- Load rating: 2500lbs.
- Weight of +0 offset: ~19.9lbs.
- Backspacing for +0 is 4.75", -6 is 4.51", -12 is 4.28", -25 is 3.77"
- Includes billet aluminum center caps.
- Compatible with TPMS.
- Not compatible with OEM lug nuts. Conical lug nuts will need to be purchased to install wheels.
Features:
- Deep stepped lip.
- Forged construction makes the wheels about 15-20% lighter, but stronger, than regular cast wheels.
- Made from Forged 6061-T Aircraft Grade aluminum.
- Superior paint finish.
- Billet aluminum CNC machined caps are included for all wheels.
- Refined larger chamfers lighten weight and disperse laterals better in FEA testing.
- Flawless precision machining.
- For those looking for maximum weight efficiency, the -S model is another 20% lighter than the -H in the same model/offset (ex: 20lbs vs 24lbs).
Vehicle fitment:
- 5x150: Tundra (2021-2007).
- 6x5.5: Tacoma (2023 and older), 4Runner, FJ, 2022+ Tundra, Lexus GX470.
Manufactured in a JWL/VIA Certified Facility and tested to meet and exceed OEM specifications.
