Description
Lightweight, Rigid, and Built for Clearance
The Crossmember Delete Front Bumper delivers maximum strength and trail clearance without unnecessary weight. Constructed from 3/16” A36 steel with 1 ¾” × .120 DOM tubing and 1 ½” × .120 wall side supports, this one-piece bumper weighs just 66 lbs while still providing secure recovery points thanks to its laminated D-ring plate design.
Crossmember Delete Design
- Requires removal of the factory lower crossmember
- Includes a heavy-duty replacement crossmember that bolts between frame rails
- Replacement serves as the mounting base for both the skid plate and bumper
- Trimming of grille and fender caps is required for installation
Power Steering Cooler Relocation
Factory power steering cooler relocation is necessary. This kit includes everything you need:
- 10-row high-performance cooler with push-lock AN fittings
- Combination mount secures both the cooler and winch control box to the core support
Lighting Compatibility
- Side-wing mounts fit Baja Designs Squadron, S2, and similar lights
- Optional 7” light bar mount (sold separately) adds even more lighting versatility
High-Clearance Engine Skid Plate
- Built from 3/16” steel with 8 mounting points (industry standard is 6)
- Flush-mounted access panels allow easy oil changes
- Includes stainless CNC-machined washers to protect panel hardware
Frame Reinforcements Included
- Weld-on 3/16” steel frame reinforcement plates are included for added strength and long-term durability
Notes
- Power steering cooler relocation is not required if you are not deleting the factory crossmember
- All power steering & winch control box relocation components are included standard with this kit
